Filters Solutions to Simplifying Network Evolution

I. Ultra-Compact Combiners

1. What do they offer?

A) Simplification

- Simplify RF connectivity in the RF Path between the antenna and radios, supporting multiple bands

- Deploy more bands in small spaces to support migration paths to 4G and 5G



B) Compact Design

- 40 to 60% smaller size compared to traditional combiners

- Light weight makes it easier to install in smaller spaces



C) Performance

- They are equipped with smaller connectors, which improve PIM performance and further ease installation



D) Multiple Applications

- Small cells (indoor and outdoor)

- Lamp poles

- Macro sites not requiring TMAs



2. Ultra-Compact Combiners for small cell infrastructure

- more capacity with less complexity

- simplify connectivity between antennas and radios

- support multiple bands

- support LTE bands and provide a migration path to 5G



II. Tower mounted amplifiers to boost coverage footprint in rural areas

1. Values of quality TMAs

A) Balance network

B) Improve BTS sensitivity

C) Reduce dropped calls

D) Increase cell capacity

E) Offset insertion losses of RF cables, jumpers

F) Ensure optimum coverage for cell edges, weak spots and indoor locations

G) Enable high order modulation for higher traffic capacity and lower battery drain





2. Why CommScope TMAs?

A) Interoperability

- Over 500 K globally installed in the past 10 years

- 100% interoperable

- Meets all network requirements (2G, 3G, 4G, 5G)

B) Proven Performance

- Extreme Testing – physical, electrical and environmental

- KPIs – fewer dropped connections, lower PIM, coverage/capacity improvements

- Interference – reduced risk thanks to additional RF conditioning



C) Extreme Testing

- Package Drop Test – 1 meter high; minimum 13 drops; multiple surfaces

- Water Submersion – 2 hours; up to 1 meter deep; 85° C

- Corrosion Test – 30 days of continuous testing

- Vibration Test – electrical safety and CE conformity; 6 hours



D) Network Simplifications

- Compact Footprint – reducing tower/pole clutter for faster zoning approvals and deployments

- Multiband Design – including the only 5-band TMA

- Lower TCO – comprehensive solution to your RF routing

- Easily Adaptable – reconfigure the AISG logical mapping, remotely or in the field



3. TMA portfolio overview

A) Frequency Support

- Low Band – 700 MHz, 800 MHz, 900 MHz

- High Band – 1800 MHz, 2100 MHz, 2300 MHz, 2600 MHz



B) Configurations

- Single Band

- Dual Band

- Triple Band

- Quad Band

- Penta Band

C) Options

- 2, 4, 6, 8 antenna ports

- 4x4 MIMO

- RF Bypass – low band, 1400 MHz, RF routing

III. Low Loss Combiners/ Interference Mitigation Filters

1. Applications and Benefits

A) CAPEX Reduction

B) Site Sharing/ Network Modernization

C) Performance Improvement

D) Reduction of Maintenance

E) Reduced Deployment Time





2. Interference Mitigation Drivers



3. New Generation of Interference Mitigation Filters

• Low Losses
• High Power Handling
• Various Pseudo Elliptic Responses
• Simple TZ Control
• Weight & Volume Saving
• Cost Effective



IV. Outdoor Wireless Networks: Green & Sustainable Agenda

1. Eco-friendly design to reduce CommScope’s carbon footprint

• Improved antenna efficiency
• Less raw material. 1,000 tons less aluminum used by 2025
• 50% of CommScope’s BSA will use 100% recyclable GFRPP radomes by the end of 2023

2. Sustainable operations and supply chain

• Reduced electricity, water and natural gas
• 30% power saving for a single product (F4C jumpers)

3. Rethinking packaging & logistics

• 40% more products in a regular container
• Digital documentation
• Reduce single-use plastic and cardboard

4. Extending solution lifecycles

• Modular design to adapt to technology evolution
• Refurbishing
• Maintain the value of products as long as possible
